Analog-to-digital converter (ADC)
RM0008
Temperature sensor/V REFINT internal channels
The Temperature sensor is connected to channel ADCx_IN16 and the internal reference
voltage V REFINT is connected to ADCx_IN17. These two internal channels can be selected
and converted as injected or regular channels.
Note:
11.3.4
The sensor and V REFINT are only available on the master ADC1 peripheral.
Single conversion mode
In Single conversion mode the ADC does one conversion. This mode is started either by
setting the ADON bit in the ADC_CR2 register (for a regular channel only) or by external
trigger (for a regular or injected channel), while the CONT bit is 0.
Once the conversion of the selected channel is complete:
●
If a regular channel was converted:
–
–
–
The converted data is stored in the 16-bit ADC_DR register
The EOC (End Of Conversion) flag is set
and an interrupt is generated if the EOCIE is set.
●
If an injected channel was converted:
–
–
–
The converted data is stored in the 16-bit ADC_DRJ1 register
The JEOC (End Of Conversion Injected) flag is set
and an interrupt is generated if the JEOCIE bit is set.
The ADC is then stopped.
11.3.5
Continuous conversion mode
In continuous conversion mode ADC starts another conversion as soon as it finishes one.
This mode is started either by external trigger or by setting the ADON bit in the ADC_CR2
register, while the CONT bit is 1.
After each conversion:
●
If a regular channel was converted:
–
–
–
The converted data is stored in the 16-bit ADC_DR register
The EOC (End Of Conversion) flag is set
An interrupt is generated if the EOCIE is set.
●
If an injected channel was converted:
–
–
–
The converted data is stored in the 16-bit ADC_DRJ1 register
The JEOC (End Of Conversion Injected) flag is set
An interrupt is generated if the JEOCIE bit is set.
11.3.6
202/995
Timing diagram
As shown in Figure 26 , the ADC needs a stabilization time of t STAB before it starts
converting accurately. After the start of ADC conversion and after 14 clock cycles, the EOC
flag is set and the 16-bit ADC Data register contains the result of the conversion.
